Standard Equipments
- Chrome Plated Cylinder
- Welded Steel Body
- Pressure Gauge
- Pressure Adjustment
- User Manual
- 2 Year Warranty
- CE Marking
Optional Equipments
- Pressure Regulator
- V Die
- Automatic Control
- Table
- Hydraulic Sliding Cylinder
Technical Specifications
Capacity (ton) | 250 |
Working Dimension | 1300x450 |
Stroke (mm) | 400 |
Working Stroke Length (mm) | 900 |
Motor Power (kw) | 15 |
Pump (L) | 34.5 |
Downward Speed (mm/s) | 8.58 |
Rotation Speed (mm/s) | 13.03 |
Overall Dimensions (LxWxH) mm | 1200x2450x2650 |
Weight (kg) | 3100 |
