"Compact Power, Superior Precision!
CSB Servo Press Brakes combine fast operation, high precision, and energy savings of up to 65% in a compact design."

Servo Press Brake

The Servo Press Brake provides a powerful solution for modern sheet metal processing requirements with its compact construction, high precision, and energy efficiency.

Its servo-electric drive system delivers fast, controlled, and repeatable bending performance, while its Y-axis accuracy of ±0.01 mm supports high production quality. Its standard 3-axis configuration can be expanded optionally to 4 or 6 axes, allowing the CNC control system to adapt to different production requirements.

Equipped with a Siemens servo motor and gearbox, Schneider electrical components, CNC-controlled backgauge, and DSP AP + MCS laser safety system, the machine combines reliability, precision, and ease of use.

Its compact design saves valuable production space, while energy savings of up to 65% help reduce operating costs.

Standard Features:

- Axes: Standard 2 axes / Optional 3–4 axes: Y1, Y2, X, R / Optional 6 axes: Y1, Y2, X, R, Z1, Z2
- Y-Axis Accuracy: ±0.01 mm
- Y-Axis Repeatability: ±0.01 mm
- Workpiece Straightness: ≤ ±0.3 / 1000 mm
- X-Axis Accuracy: ±0.02 mm
- R-Axis Accuracy: ±0.05 mm
- CNC Control Unit: Optional
- Upper Tools: Promecam-type upper tooling
- Lower Tools: V16, V22, V35, V50 lower tools (12 TN – 60 TN)
- Tool Clamping: Promecam-type quick tool clamping system
- Crowning System: Not required
- Main Servo Motor: Servo motor with brake
- Main Gearbox: Optional
- Electrical Components: Siemens or Schneider Electric
- X- and R-Axis Servo Drives: Siemens or Veichi
- Backgauge System: CNC-controlled motorized backgauge system
- Backgauge Fingers: 2 as standard
- Safety System: DSP AP + MCS laser safety system
- Machine Frame: Heavy-duty, stress-relieved welded frame
- Servo Cylinder Structure: The linear actuator construction allows direct mounting to the upper beam using a wedge-type arrangement.
- Front Support Arms: Standard table-type support up to the 40/1300 model. Other models include 2 support arms that can be moved vertically using handwheels.
- Foot Pedal: Dual-pedal foot control with an anti-panic function and emergency stop button.
- Rear Area Safety: Rear door system with safety sensors on the 40/1300 to 60/1500 models.
- Documentation: CE Declaration of Conformity and user manual (DK, EN, DE)

General Features:

- Standard front support
- Backgauge system with up to 6 axes
- DSP AP + MCS safety system
- Promecam upper tooling
- Promecam lower tooling

Optional Equipment:

- Servo motor system for models with working lengths of 835 mm, 1300 mm, and 1500 mm
- 4–6-axis backgauge system
- Automatic lubrication
- Aluminum control arm panel

Technical Specifications:
